RedEdge MX with DJI SkyPort
$6,300.00
Product/Service Overview:
- Metal case for extreme durability
- DLS 2 for enhanced light calibration
- Captures five narrow spectral bands
- Generates plant health indexes and RGB (color) images from one flight
- Designed for easy and flexible integration
- Calibrated for precise, repeatable measurements
- Operates in temperatures up to 60℃ or 140℉
Kit includes: RedEdge-MX, DLS 2 with embedded GPS, Calibrated Reflectance Panel, lens cover and hard carrying case.
Key Features:
FLY
The RedEdge-MX’s low weight, low power requirement, and ability to capture RGB and narrowband spectral bands simultaneously means you can gather the data you need in fewer flights. Have multiple UAVs? RedEdge-MX quickly integrates with many different drone platforms.
PROCESS
With RedEdge-MX, you own your data. You’re not limited to a particular processing platform. You can choose whichever platform is best for you, your customer, or your project.
ANALYZE
RedEdge-MX has five bands—blue, green, red, red edge, and near-infrared—that our research showed were optimal for sensing crop health. It simply shows you more. And with MicaSense Atlas, you can see many different analytical layers in one easy to use interface, and compare these outputs across time.
ANYWHERE
We know you need tools you can rely on. That’s why we built the sensors we wanted in the field—predictable, tough, and reliable—so you can gather the data you need when you need it.
Specifications:
| Weight: | 231.9 g (8.18 oz.)
(includes DLS 2 and cables) |
| Dimensions: | 8.7cm x 5.9cm x 4.54cm
(3.4in x 2.3in x 1.8in) |
| External Power: | 4.2 V DC – 15.8 V DC
4 W nominal, 8 W peak |
| Spectral Bands: | Blue, green, red, red edge, near-IR
(global shutter, narrowband) |
| Wavelength (nm): | Blue (475 nm center, 20 nm bandwidth), green (560 nm center, 20 nm bandwidth), red (668 nm center, 10 nm bandwidth), red edge (717 nm center, 10 nm bandwidth), near-IR (840 nm center, 40 nm bandwidth) |
| RGB Color Output: | Global shutter, aligned with all bands |
| Ground Sample Distance (GSD): | 8 cm per pixel (per band) at 120 m (~400 ft) AGL |
| Capture Rate: | 1 capture per second (all bands), 12-bit RAW |
| Interfaces: | Serial, 10/100/1000 ethernet, removable Wi-Fi, external trigger, GPS, SDHC |
| Field of View: | 47.2° HFOV |
| Triggering Options: | Timer mode, overlap mode, external trigger mode (PWM, GPIO, serial, and Ethernet options), manual capture mode |
| Weight: | 231.9 g (8.18 oz.)
(includes DLS 2 and cables) |
| Dimensions: | 8.7cm x 5.9cm x 4.54cm
(3.4in x 2.3in x 1.8in) |
| External Power: | 4.2 V DC – 15.8 V DC
4 W nominal, 8 W peak |
| Spectral Bands: | Blue, green, red, red edge, near-IR
(global shutter, narrowband) |
| Wavelength (nm): | Blue (475 nm center, 20 nm bandwidth), green (560 nm center, 20 nm bandwidth), red (668 nm center, 10 nm bandwidth), red edge (717 nm center, 10 nm bandwidth), near-IR (840 nm center, 40 nm bandwidth) |
Additional Information
| Weight | 12 kg |
|---|---|
| Dimensions | 30 × 30 × 30 cm |
